Sphere Series

Vegaview 2.5 PAPR

Product #: 4442.801

World record ADF with shade level 2.5 / 8–12: The Optrel Vegaview 2.5 lets the welders’ most desired wish come true: bright view. With its unrivaled brightest ADF view with shade level 2.5, Vegaview 2.5 improves the visibility of welders’ environment by 400%! Compared with traditional autodarkening welding helmets, Vegaview 2.5 sets the world record in the light state! Thanks to a special UV/IR filter, the Vegaview 2.5 offers a real color experience never seen before and finally brings color into the world of welding. Weighing only 482 g (17 oz), the Optrel Vegaview 2.5 is one of the lightest auto­darkening welding helmets available. Its ergonomic design minimizes strain on the head and neck, ensuring comfort throughout the work day. The Optrel Vegaview 2.5 is perfectly combined with the Optrel e3000 PAPR respiratory system. With its integrated high-performance particle filter (TH3), welders are adequately protected against smoke, aerosols, and dust.

Helmet ONLY. Compatible with the e3000x NIOSH-approved PAPR system.

List Price:

$733.00

Features

An icon for "Respiratory Protection" represented by a vector-shaped lungs of a human body.

Respiratory Protection

Face and respiratory protection system when combined with the e3000x blower kit
Icon for "Shadetronic" represented by its text inside a circle with scale showing increasing decibels.

ShadeTronic®

Automatically adapts to changing light conditions of the welding arc
Icon for "True Color View" represented by three circles intersecting.

True-Color View

Like looking through a glass window
Icon for "Delay Function" represented by an arch and the number one, two, and three.

Delay Function

Delay Function Feature
Icon for "Grinding Mode" represented by angle grinder disc.

Grinding Mode

The brightest vision during grinding work ever to be offered by a welding helmet
Icon for "Overhead Welding" represented by grinding disc and impact drill.

Overhead Welding

Overhead Welding Feature
Icon for "Patented Eccentric" represented by grinding disc and impact drill.

Patented Excenter

Positions the helmet optimally on your head – with just one twist
Icon for "Sensitivity Regulation" represented by a welding helmet and sun.

Sensitivity Regulation

Adapts the helmet to your environment and requirements
Icon for "Construction Helmet Adapter" represented by a side view of a hard hat.

Hard Hat Adapter

Compatible with industrial construction helmet adapter accessory
An icon for "Warranty Extension of 2+1 Years" represented by numbers two and one.

Warranty Extension

Simply register here to be covered for 3 years after purchase
An icon for "External Operability" represented by ___

External Operability

Toggle grind mode and shade level adjustments without removing your helmet

Specifications

Light transmittance Ultraviolet-/infrared protection (maximum at any shade setting)
Infinite exterior shade level setting
Visible range activated: shade level 8 – 12
Visible range not activated: shade level 2.5
Power supply 2 pcs batteries 3V exchangeable (CR2032)
Operating time batteries Approx. 3000 hours (operating)
Sensors 3 sensors, variable detection angle with movable sensor slider
Switching time Light to dark: 0.100 ms at room temperature
0.070 ms at 55°C / 131°F
Dark to light: from 0.05 s to 1.0 s adjustable
Classification Optical class: 1
Scattered light: 1
Homogeneity: 1
Angular dependence:2
Shape stability Welding mask: up to 220°C / 428°F
Front cover lens: up to 137°C / 279°F
Protection for ADF Reflection free front cover lens and inside cover lens
Mask material PA6.6
Operating temperature -10°C to +70°C / 14°F to 158°F
Storage temperature -20°C to +80°C / -4°F to 176°F
Weight Welding helmet: 482 g, 17.002 oz
Scope of delivery Welding helmet, instruction manual, storage bag, batteries, warranty card and one front cover lense
Warranty 2 years with additional 1 year warranty extension (excluding battery) if the product is registered within the first 6 months: click here to register

Applications

  • Elektrode Welding (Stick Welding, SMAW)
  • MIG/MAG (GMAW)
  • GMAW High melting rate process
  • Flux Cored Wire Welding
  • TIG Welding (GTAW)
  • Plasma Arc Welding
  • Micro Plasma Arc Welding
  • Plasma Cutting
  • Gas Welding
  • Grinding
